Bambach 3.3mm2 TINNED Low Voltage Garden Light Cable 46/0.3mm, ENTER YOUR LENGTH
Very heavily PVC insulated. Australian made Bambach brand is the ultimate LV garden light cable
Beware of cheap inferior imported product
(Quality PVC insulation & tinning is critical for long term use)
Sold here priced per lineal metre, cut to your required length from the reel
Suitable for garden lights and extension cables for low voltage pond pumps. Ideal for hundreds of metres long runs with our 24V-12V MultiVolt 4W LED system.
Very heavily PVC insulated TINNED copper. Australian made Bambach brand is the ultimate LV garden light cable
Beware of cheap inferior imported product
(Quality PVC insulation & tinning is critical for long term use)
Sold here priced per lineal metre, cut to your required length from the reel
Also available as a discounted 50m reel or 100m reel.
Quality tinned copper wire cable manufactured in Australia (Rosedale Vic) by Bambach Wire and Cables Pty Ltd.
Heavy Duty Insulated Low Voltage Cable - sold per metre
Specifications:
- Each conductor is approx 2.2mm diameter & contains 46 x 0.3mm diameter tinned annealed copper strands giving a total area of approximately 3.3mm².
- Cable outside dimensions approx 9.1mm x 4.9mm.
- Current Rating: 26Amps
- Oxygen free tinned annealed copper wire, class 5. 78036BK is plain copper
- Applicable Standards: AS/NZS1125, AS/NZS3808, AS/NZS1660.5.6, IEC 60228, IEC 60332-1
Benefits:
- Tinned copper wire cable protects the conductors from corrosion, extending the life in marine applications by many years.
- Tinning gives the cable better quality soldered connections.
- Suitable for continuous operating at high temperatures
- Easy to Install: Class 5 flexible conductor stranding for easy installation
- Extremely thick but still flexible black PVC insulation allows for a small bending radius
- Insulation on opposing conductors is a different profile for easy polarity identification in DC applications.
Features:
- Fine conductor stranding for high flexing.
- RoHS compliant to meet European standards
- Oxygen free copper for high conductivity soldered connections
Rating:
- Temperature: -10°C to + 90°C
- Voltage: Maximum 32V - Not suitable for connection to mains
- Max Current: 26Amps:
With our 4W MultiVolt 12V-24V LED MR16 bulbs powered by a Aqualux 24VAC AQO24-100 transformer, this cable will allow trunk runs of hundreds of metres. Even though the voltage at the end may have dropped from 24V to only 12V, the lamps will still work perfectly.
It is capable of carrying the "higher pressure" 24V AC for 60m as an extension cable for 24V Low Voltage pond pumps from a 24V transformer.
Country of Manufacture: Australia (Rosedale Vic)
For Aqualux 24V/12V Voltage Drop Calculator regarding cable sizing & distance, click link
